Pull Out Tray

Regular price $895.00 Save $-895.00


6 in stock

Want a professional-looking storage solution for your mountain bikes, cooler, or other accessories? The Pull Out Tray is our answer.

The Pull Out Tray is designed to stow gear and other accessories for easy access via the rear doors of your adventure van. Stop crawling into the back of your van, and start loading up for your next adventure. The heavy-duty slide outs make it faster and easier to access your bikes or cooler so you can party in the back - it's like a mullet for your adventure van.

Heavy-duty drawer glides rated for up to 500 pounds locks in the stow position and when fully extended. Another key feature is the circular hole with a removable plug for easy cleaning and draining. We all know how enticing a little hero dirt can be, but we've also seen the debris that can get leftover in your pull out tray.

There are multiple holes (12 total) on the bottom of the slide out tray for mounting. (Note: The tray comes completely assembled but does not come with mounting hardware. The size of hardware and method for mounting should be decided by you and/or your builder to properly mount the slide out tray in your chosen location. Please mount to the floor taking into account the weight you are placing on the tray. If you are unsure, always talk to a professional.)

Key Features and Specifications

  • Heavy-duty 500lb. locking slides - Zinc plated to prevent rust.
  • Lock in and Lock out. The tray locks when fully retracted and fully extended.
  • Circular hole with plastic cover included for easy clean up and draining.
  • Comes with 12 mounting holes - 6 per side.
  • Inner tray dimensions: 59 7/8" long by 17 3/4" wide.
  • Outer tray dimensions: 61" long x 19 3/4" wide x 3" deep.
  • Rocky Mounts bike mounts shown in pictures are compatible but not included.

Designed to Hold Bikes, Coolers, and Grills

When we designed the Pull Out Tray we wanted to make sure it could accommodate the wide range of gear that’s stored in the garage area of adventure vans. The trays are large enough to hold two full-size mountain bikes using the Rocky Mounts fork bike mounts. We’ve also had customers use it to store coolers and even their grilling setup.

Customer Reviews

Based on 4 reviews
75%
(3)
25%
(1)
0%
(0)
0%
(0)
0%
(0)
R
Rob J.

Very well made. Definitely recommend this product

D
Daniel C.
Great Customer Service. Easy Install

Considered building my own, but after going through my van build to this point, I understand the value of quality pre-built components and my time. Sliders professional and have great build quality. Customer service team was great, getting my sliders delivered to me in the Portland area in less than 24 hours! Only one small nit, product description says 5 holes per side when in fact it’s 6.

N
Neil
Another amazing product

Silas and the boys at Flatline Van Co have done it again and turned out another great product. The pull out tray is top quality and is the perfect addition to my Adventure Van. It holds just the right amount of gear and allows me to get it in and out without having to crawl deep into the van. I highly recommend it.

M
Matt P.
B+.......

This tray functions fine, but for the overall price, I expected a bit more. I am satisfied, but the popularity of modifying vans likely drove much of the price on this element. The base is not laterally stable, it only being stabilized by the tray-would have expected lateral pieces mid/point and end-point. The tray sits too low in respect to the floor. There is not enough clearance for a standard 1/4 inch nut to hold a rocky mount without scraping any floor molding you might install. I assume most vans will have insulation and finish flooring, as well as some type of molding as part of any customization. Small items I suppose, but for $900 +, expected a A+, not a b +. Thanks for the feedback forum !!
